14 Inch Android Tablet PC Touch Screen Monitor RK3568 1920x1080 IPS AIO PC

14 Inch Android Tablet PC Touch Screen Monitor RK3568 1920x1080 IPS AIO PC
14 Inch Android Tablet PC Touch Screen Monitor RK3568 1920x1080 IPS AIO PC 14 Inch Android Tablet PC Touch Screen Monitor RK3568 1920x1080 IPS AIO PC 14 Inch Android Tablet PC Touch Screen Monitor RK3568 1920x1080 IPS AIO PC 14 Inch Android Tablet PC Touch Screen Monitor RK3568 1920x1080 IPS AIO PC 14 Inch Android Tablet PC Touch Screen Monitor RK3568 1920x1080 IPS AIO PC 14 Inch Android Tablet PC Touch Screen Monitor RK3568 1920x1080 IPS AIO PC 14 Inch Android Tablet PC Touch Screen Monitor RK3568 1920x1080 IPS AIO PC

Large Image :  14 Inch Android Tablet PC Touch Screen Monitor RK3568 1920x1080 IPS AIO PC

Product Details:
Place of Origin: ShenZhen / China
Brand Name: SAEF
Certification: ISO9001 / ISO14000
Model Number: NX140T-3568
Payment & Shipping Terms:
Minimum Order Quantity: 2 pcs
Price: Negotiable based on order quantity
Packaging Details: Standard Exportation Package
Delivery Time: 1-5 weeks
Payment Terms: L/C, T/T, Western Union, Paypal
Supply Ability: 10K pcs per month

14 Inch Android Tablet PC Touch Screen Monitor RK3568 1920x1080 IPS AIO PC

Description
Product: 14 Inch Android Touch Screen Monitor Resolution: 1920×1080
Brightness: 350 Cdm2 Display Area: 16:9, 309×174mm
CPU: Rockchip RK3568 RAM: 4GB
ROM: 32GB System: Android 11
WIFI: 802.11b/g/n Network: WIFI/Ethernet/Bluetooth/3G/4G/microphone
Interface: SD/USB/RJ45/Earphone/Power Multi-Media: Video/Audio/Picture
Speaker: 2×2W Speakers Camera: Standard 200W Pixel Camera
Software: Free Installation Applications Adapter: DC-In 12V/2A
User's Manual: One POE: Optional
Highlight:

14 Inch Android Tablet PC

,

RK3568 Android Tablet PC

,

1920x1080 IPS AIO PC



14 Inch Android Tablet Touch Screen Monitor IPS AIO PC RK3568 1920x1080 Android Tablet PC Product Introduction



I. Exceptional Performance

  1. Powerful Computation: Equipped with the RK3568 processor featuring a quad - core Cortex - A55 architecture, it offers outstanding computing capabilities. Whether you're running office software, browsing the web, playing games, or watching videos, it responds rapidly. This ensures a seamless operation experience, free from noticeable lags.
  1. HD Display: The 14 - inch IPS screen with a resolution of 1920x1080 delivers clear and vivid visual effects. Its ultra - wide viewing angle design allows the screen to maintain vivid colors and high contrast when viewed from different angles, providing users with an immersive visual enjoyment.

II. Abundant Configuration

  1. Memory and Storage: It comes with an option of 4GB or 8GB of RAM, enabling easy multitasking. Additionally, it supports 64GB or 128GB of internal storage (optional), meeting users' demands for storing numerous applications, files, photos, and videos. There's also a TF card slot for further storage expansion.
  1. Operating System: Running on the Android system, it has a rich application ecosystem. Users can download various apps from the Google Play Store or other platforms, covering office, entertainment, learning, social networking, etc., to satisfy diverse usage needs.
  1. Network Connection: Supporting 802.11ac dual - band Wi - Fi, it offers stable and fast wireless network connections. Meanwhile, the RJ45 Ethernet interface caters to scenarios with high - stability network requirements. It also supports Bluetooth 5.0, facilitating connections to various Bluetooth devices like keyboards, mice, and headphones.
  1. Touch Screen: Adopting a high - precision capacitive touch screen that supports 10 - point touch, it's highly sensitive and responsive. Users can easily complete operations like swiping, zooming, and clicking, bringing a convenient interactive experience.

III. Distinctive Advantages

  1. Lightweight and Portable: With a 14 - inch size and a lightweight body, it's easy to carry. Whether you're traveling, working, or in daily use, it can be effortlessly placed in a backpack or handbag, meeting users' needs anytime, anywhere.
  1. Multi - function Integration: As an All - in - One (AIO) PC, it combines the functions of a tablet and a computer. You can either operate it like a tablet for a convenient mobile experience or connect a keyboard and mouse to use it as a computer for efficient office work and creation.
  1. High Cost - effectiveness: Despite its powerful performance and rich configuration, it has a reasonable price. Compared with high - end products of the same type, it offers better cost - effectiveness, providing users with a more valuable choice.

IV. Diverse Application Scenarios

  1. Office and Learning: It allows the installation of various office software such as Word, Excel, and PowerPoint, meeting daily office needs for document editing, data processing, and presentation making. In learning, it supports online learning platforms, e - textbooks, and learning apps to assist students in learning and review.
  1. Entertainment and Leisure: Its large screen and high - definition display make it an ideal device for watching movies, TV shows, and playing games. The rich application ecosystem provides various entertainment apps like video players, music players, and game centers, allowing users to enjoy their leisure time.
  1. Business Display: It can be used for information display in commercial places, such as e - menus in restaurants, promotional information display in malls, and room information inquiries in hotels. Through customized applications, it provides merchants with efficient information dissemination and customer service tools.
  1. Industrial Control: With its stable performance and rich interfaces, it can be applied in the industrial control field, such as equipment monitoring, data collection, and production line management, providing reliable solutions for industrial automation.

Product Information

Display Screen 14 inch FULL HD IPS screen
Resolution 1920×1080
Brightness 350 cdm2
Contrast 1000:1
Screen scale/Display area 16:9/ Display area :309×174mm
Configuration CPU Rockchip RK3568 quad core A55 processor, clocked 2.0GHz
RAM 4GB
ROM 32GB
System Android 11 system
Network WIFI 802.11b/g/n/ac
Ethernet Supports connection to the RJ45 network interface
Bluetooth Bluetooth 4.0
3G/4G Support external 3G/4G USB dongle
Built-in POE Optional
Built-in battery Optional
Jack TF 1×TF card slots (max support 32GB)
USB 2.0 1×USB 2.0 interface (support U disk, mouse, keyboard, printer etc)
USB 3.0 1×USB 3.0 interface
RJ45 1xRJ45
Earphone 1×3.5mm headphone jack
HDMI out 1xHDMI out
Power 1×5.5x2.1mm power DC jack
Multi-Media Video Support MPEG-1, MPEG-2, MPEG-4, H.263, H.264, RV, etc. (max support 1080P)
Audio Support MP3, WMA, AAC and so on
Picture JPEG,JPG
Other parameters Wireless mouse keyboard Support
Speaker 2×2W speakers
Camera Standard 200W pixel camera (500W pixel camera optional)
OSD language Chinese, English, German, Korean, Russian, French, Spanish, Arabia etc OSD operations
Software support Free installation applications (maps, games, e-mail, self developing apps, etc.)
Attachment Adapter One, specifications: 12V/2A
Desktop Bracket One
Remote control Optional
User's Manual One
Theftproof cover plate One, (can cover insert devices, such as U disk or SD card, to prevent theft)


Product Size

Body Size Color Box 10pcs/Carton
Length Width Thickness Length Width Height Length Width Height
391 240 30 440 350 76 445 400 730
N.W: 1.5KG N.W: 2.18KG G.W:22.8KG
Unit: mm






14 Inch Android Tablet PC Touch Screen Monitor RK3568 1920x1080 IPS AIO PC 014 Inch Android Tablet PC Touch Screen Monitor RK3568 1920x1080 IPS AIO PC 114 Inch Android Tablet PC Touch Screen Monitor RK3568 1920x1080 IPS AIO PC 2



14 Inch Android Tablet PC Touch Screen Monitor RK3568 1920x1080 IPS AIO PC 314 Inch Android Tablet PC Touch Screen Monitor RK3568 1920x1080 IPS AIO PC 414 Inch Android Tablet PC Touch Screen Monitor RK3568 1920x1080 IPS AIO PC 5
