Wall Mounted Android All In One Tablet RK3399 18.5 Inch 1920x1080 IPS POE RJ45 No Camera

Wall Mounted Android All In One Tablet RK3399 18.5 Inch 1920x1080 IPS POE RJ45 No Camera
Wall Mounted Android All In One Tablet RK3399 18.5 Inch 1920x1080 IPS POE RJ45 No Camera Wall Mounted Android All In One Tablet RK3399 18.5 Inch 1920x1080 IPS POE RJ45 No Camera Wall Mounted Android All In One Tablet RK3399 18.5 Inch 1920x1080 IPS POE RJ45 No Camera Wall Mounted Android All In One Tablet RK3399 18.5 Inch 1920x1080 IPS POE RJ45 No Camera Wall Mounted Android All In One Tablet RK3399 18.5 Inch 1920x1080 IPS POE RJ45 No Camera Wall Mounted Android All In One Tablet RK3399 18.5 Inch 1920x1080 IPS POE RJ45 No Camera

Large Image :  Wall Mounted Android All In One Tablet RK3399 18.5 Inch 1920x1080 IPS POE RJ45 No Camera

Product Details:
Place of Origin: China
Brand Name: OEM
Certification: 3C,FCC,CE,ROHS etc.
Model Number: N185N-3399
Payment & Shipping Terms:
Minimum Order Quantity: 2
Price: Negotiable based on order quantity
Packaging Details: 5pcs per carton, securely packaged.
Delivery Time: 1-5 weeks
Payment Terms: L/C, T/T, Western Union, Paypal
Supply Ability: 10k pcs per months

Wall Mounted Android All In One Tablet RK3399 18.5 Inch 1920x1080 IPS POE RJ45 No Camera

Description
Panel: 18.5" High-definition Full View Screen Resolution: 1366×768 (1920x1080 Optional)
Viewing Angle: 85/85/85/85(L/R/U/D) Brightness: 300 Cd/m2
Screen Scale/Display Area: 16:9/ Display Area : 409×229mm CPU: Rockchip RK3399 Dual Core Cortex-A72 Up To 1.8GHz+quad Core Cortex-A53 Up To 1.4GHz
RAM: 4GB Internal Memory: 16GB (32GB Optional)
Operation System: Android 7.1/8.1/9.0/10/11 OS Touch Screen: 10-Point Capacitive Touch (optional)
Network: WIFI,Ethernet,Bluetooth,4G/5G Cellular Network Interface: TF, USB 2.0,USB 3.0,RJ45,Earphone,HDMI Out,Power
Camera: Non Speaker: 2×3W Speakers
Adapter: 12V/3A Desktop Bracket: Non (Optional)
Microphone: Non (Optional)
Highlight:

1920x1080 Android All In One Tablet

,

RK3399 Android All In One Tablet

Wall Mounted Android All In One Tablet RK3399 18.5 Inch 1920x1080 IPS POE RJ45 No Camera product Introduction



Configuration Highlights

This Android tablet is powered by the high - end Rockchip RK3588 octa - core 64 - bit architecture processor. With 4 high - performance Cortex - A76 cores for heavy - duty tasks and 4 energy - efficient Cortex - A55 cores for general operations, it strikes a perfect balance between performance and power consumption. The base model comes with 4GB of DDR4 RAM, which can be expanded to 8GB for more demanding multitasking scenarios. For storage, it offers 64GB of internal eMMC storage, and you have the option to upgrade to 128GB, ensuring ample space for all your apps, files, and media.

Exceptional Performance

Thanks to its powerful processor and sufficient memory, this tablet can handle multitasking with ease. Whether you're running multiple productivity apps simultaneously, editing high - resolution photos, or streaming 1080P videos while browsing the web, it operates smoothly without any lag. The 18.5 - inch IPS display with a resolution of 1920x1080, 85/85/85/85 viewing angles, 300 cd/m² brightness, and 1000:1 contrast ratio provides a sharp, clear, and immersive visual experience.

Versatile Application Scenarios

In industrial settings, it can be used for real - time monitoring of industrial equipment. Its stable network connectivity, including 100M (upgradable to 1000M) wired network via the RJ45 Ethernet interface (POE optional) and 802.11b/g/n Wi - Fi, ensures seamless data transfer. In retail, it serves as an e - price tag or self - checkout device, enhancing the shopping experience. In educational institutions, it supports interactive multimedia teaching, making learning more engaging. In medical facilities, it can be used for displaying patient data and controlling medical equipment, contributing to more efficient healthcare services.

product Introduction
Display Panel 18.5" high-definition full view screen
Resolution 1920x1080
Viewing angle IPS Screen 85/85/85/85(L/R/U/D)
Brightness 300 cd/m2
Contrast 1000:1
Screen scale/Display area 16:9/ Display area : 409×229mm
System CPU Rockchip RK3399 Dual core Cortex-A72 up to 1.8GHz+quad core Cortex-A53 up to 1.4GHz
RAM 4GB
Internal memory 16GB (32GB optional)
Operation system Android 7.1/8.1/9.0/10/11 OS
Touch screen No 10-Point capacitive touch
Network WIFI 802.11b/g/n
Ethernet 100M ethernet (1000M optional)
Bluetooth BT 5.2
4G/5G Cellular network Optional
Interface TF TF card slots
USB 2.0 1×USB 2.0 interface (support U disk, mouse, keyboard, printer etc)
USB 3.0 1×USB 3.0 interface (support U disk, mouse, keyboard, printer etc)
RJ45 Ethernet interface (POE function Optional)
Earphone 1×3.5mm headphone Interface
HDMI out 1xHDMI out
Power DC power input (5.5x2.1)
Multi-Media Video Support MPEG-1, MPEG-2, MPEG-4, H.263, H.264, RV, etc. (max support 1080P)
Audio Support MP3, WMA, AAC and so on
Picture JPEG,JPG
Other parameters Microphone No
Speaker 2×3W speakers
Camera No
Working temp 0-50degree
OSD language Multi-language
Certificates 3C,FCC,CE,ROHS etc.
Attachment Adapter yes, specifications: 12V/3A
User's Manual yes
Desktop Bracket No


Product Size

Body Size Color Box 5pcs/Carton
Length Width Thickness Length Width Height Length Width Height
447 267 41 502 429 87 515 450 445
N.W 2.76KG N.W 3.46KG N.W 17.3KG
            G.W 18.3KG
Unit: mm
