18.5 Inch Android Smart Terminal RK3128 1920x1080 IPS Display With POE RJ45 Port All In One Tablet PC

18.5 Inch Android Smart Terminal RK3128 1920x1080 IPS Display With POE RJ45 Port All In One Tablet PC
18.5 Inch Android Smart Terminal RK3128 1920x1080 IPS Display With POE RJ45 Port All In One Tablet PC 18.5 Inch Android Smart Terminal RK3128 1920x1080 IPS Display With POE RJ45 Port All In One Tablet PC 18.5 Inch Android Smart Terminal RK3128 1920x1080 IPS Display With POE RJ45 Port All In One Tablet PC 18.5 Inch Android Smart Terminal RK3128 1920x1080 IPS Display With POE RJ45 Port All In One Tablet PC 18.5 Inch Android Smart Terminal RK3128 1920x1080 IPS Display With POE RJ45 Port All In One Tablet PC 18.5 Inch Android Smart Terminal RK3128 1920x1080 IPS Display With POE RJ45 Port All In One Tablet PC 18.5 Inch Android Smart Terminal RK3128 1920x1080 IPS Display With POE RJ45 Port All In One Tablet PC

Large Image :  18.5 Inch Android Smart Terminal RK3128 1920x1080 IPS Display With POE RJ45 Port All In One Tablet PC

Product Details:
Place of Origin: China
Brand Name: OEM
Certification: 3C,FCC,CE,ROHS etc.
Model Number: N185N-3128
Payment & Shipping Terms:
Minimum Order Quantity: 2
Price: Negotiable based on order quantity
Packaging Details: 5pcs per carton, securely packaged.
Delivery Time: 1-5 weeks
Payment Terms: L/C, T/T, Western Union, Paypal
Supply Ability: 10k pcs per months

18.5 Inch Android Smart Terminal RK3128 1920x1080 IPS Display With POE RJ45 Port All In One Tablet PC

Description
Panel: 18.5" High-definition Full View Screen Resolution: 1366×768 (1920x1080 Optional)
Viewing Angle: 85/85/85/85(L/R/U/D) Brightness: 300 Cd/m2
Screen Scale/Display Area: 16:9/ Display Area : 409×229mm CPU: Rockchip RK3128 Quad Core Cortex-A7, With A Frequency Of Up To 1.2GHz
RAM: 1GB Internal Memory: 16GB
Operation System: Android 7.1 OS Touch Screen: 10-Point Capacitive Touch (optional)
Network: WIFI,Ethernet,Bluetooth,4G/5G Cellular Network Interface: TF, USB 2.0,USB 3.0,RJ45,Earphone,HDMI Out,Power
Camera: Non Speaker: 2×3W Speakers
Adapter: 12V/3A Desktop Bracket: Non (Optional)
Microphone: Non (Optional)
Highlight:

1920x1080 Android Smart Terminal

,

RK3128 All In One Tablet PC

,

18.5 Inch Android Smart Terminal

18.5 - Inch Android Smart Terminal RK3128 All - in - One Tablet PC product Introduction



Exceptional Display

This 18.5 - inch Android smart terminal features a stunning 1920x1080 IPS display. With its high - resolution panel, every image and text appears sharp and vivid, delivering a truly immersive visual experience. The IPS technology ensures an ultra - wide viewing angle, allowing you to view the screen clearly from any direction without color distortion or loss of clarity. Whether it's for digital signage, industrial control, or interactive kiosk applications, the display quality meets the highest standards.



Powerful Performance

Equipped with the RK3128 processor, this all - in - one tablet PC offers reliable performance. It can handle multitasking with ease, running multiple applications simultaneously without significant lag. Whether you're using it for data processing, running business software, or playing multimedia content, the RK3128 ensures smooth operation. Coupled with a well - optimized Android system, it provides a user - friendly interface and quick response times.



Seamless Connectivity

The inclusion of a POE (Power over Ethernet) RJ45 port simplifies the setup process. With POE, you can power the device and establish a network connection using a single Ethernet cable. This not only reduces cable clutter but also makes installation in hard - to - reach places more convenient. It's perfect for applications where a stable network connection is essential, such as in industrial settings, offices, or public areas where the device needs to communicate with other systems in real - time.



Versatile All - in - One Design

As an all - in - one tablet PC, it combines the functionality of a computer and a display into a single, compact unit. This space - saving design makes it suitable for various environments, from small offices to large - scale industrial facilities. It can be easily wall - mounted or placed on a desk, providing flexibility in usage scenarios. Whether you need it for information display, as a control panel, or for educational purposes, this device adapts to your needs.

Display Panel 18.5" high-definition full view screen
Resolution 1920x1080
Viewing angle IPS Screen 85/85/85/85(L/R/U/D)
Brightness 300 cd/m2
Contrast 1000:1
Screen scale/Display area 16:9/ Display area : 409×229mm
System CPU Rockchip RK3128 quad core Cortex-A7, with a frequency of up to 1.2GHz
RAM 1GB
Internal memory 16GB
Operation system Android 7.1 OS
Touch screen No 10-Point capacitive touch
Network WIFI 802.11b/g/n
Ethernet 100M ethernet (1000M optional)
Bluetooth BT 4.2
4G/5G Cellular network Optional
Interface TF TF card slots
USB 2.0 1×USB 2.0 interface (support U disk, mouse, keyboard, printer etc)
USB 3.0 1×USB 3.0 interface (support U disk, mouse, keyboard, printer etc)
RJ45 Ethernet interface (POE function Optional)
Earphone 1×3.5mm headphone Interface
HDMI out 1xHDMI out
Power DC power input (5.5x2.1)
Multi-Media Video Support MPEG-1, MPEG-2, MPEG-4, H.263, H.264, RV, etc. (max support 1080P)
Audio Support MP3, WMA, AAC and so on
Picture JPEG,JPG
Other parameters Microphone No
Speaker 2×3W speakers
Camera No
Working temp 0-50degree
OSD language Multi-language
Certificates 3C,FCC,CE,ROHS etc.
Attachment Adapter yes, specifications: 12V/3A
User's Manual yes
Desktop Bracket No


Product Size

Body Size Color Box 5pcs/Carton
Length Width Thickness Length Width Height Length Width Height
447 267 41 502 429 87 515 450 445
N.W 2.76KG N.W 3.46KG N.W 17.3KG
            G.W 18.3KG
Unit: mm
