Product Details:
|
| Screen Size: | 18.5 Inches | Display Area: | 409×229mm |
|---|---|---|---|
| Camera: | No | Processor: | Quad-core Rockchip RK3566 |
| Surface Luminance: | 300 Cd/m2 (nits) | POE: | Optional |
| Bluetooth: | BT 5.2 | Working Temp: | 0-50degree |
| RAM: | 2GB | Internal Memory: | 16GB |
| Operation System: | Android 11/13 OS | Touch Screen: | 10-Point Capacitive Touch |
| Interface: | TF，USB 2.0，USB 3.0，RJ45，Earphone，HDMI Out，Power | Software: | Free Installation Applications |
| Highlight: | 18.5 Inch Android Touch Screen Monitor,KR3568 Android Touch Screen Monitor,IPS Display Android Touch Screen Monitor |
||
18.5 Inch Android Touch Screen Monitor KR3568 IPS Display No Camera Vesa Wall Mounted With POE RJ45 Port Product Introduction
Exceptional Display
High - Def Panel: 18.5" full - view screen, crafted for immersive visuals in every scenario.
Sharp Resolution: 1920x1080, delivering crystal - clear images for work, play, and digital signage.
Ultra - Wide IPS Viewing: 85/85/85/85 (L/R/U/D) angle, ensuring consistent clarity from any position.
Ideal Brightness: 300 cd/m², adaptable to various lighting setups.
High Contrast: 1000:1 ratio for vivid colors and deep blacks.
Optimal Scale: 16:9 format with a 409×229mm display area for seamless multitasking.
Robust System
Powerful CPU: Rockchip RK3566 Quad Core 64 - bit Cortex - A55, ensuring smooth operation under any load.
Flexible RAM: 2GB (4GB optional) for quick data handling and multitasking.
Ample Storage: 16GB (32GB optional) of internal memory, expandable to fit your needs.
Latest OS: Runs on Android 11/13, offering a user - friendly interface and app compatibility.
Versatile Connectivity
Wireless WIFI: 802.11b/g/n for stable wireless internet access.
Wired Ethernet: 100M (1000M optional) for high - speed, reliable connections.
Bluetooth 5.2: Effortless pairing with external devices.
Optional 4G/5G: Stay connected on - the - go.
Rich Interfaces
TF Slots: For easy storage expansion.
USB 2.0 & 3.0: Connect U disks, mice, keyboards, and more.
RJ45 w/POE Option: Stable network with power - over - ethernet flexibility.
3.5mm Headphone Jack: Private audio enjoyment.
HDMI Out: Connect to larger displays.
DC 5.5x2.1 Power Input: Reliable power supply.
Multimedia - Ready
Video Support: MPEG - 1, MPEG - 2, MPEG - 4, H.263, H.264, RV (up to 1080P).
Audio Compatibility: MP3, WMA, AAC, etc., with 2×3W speakers.
Image Compatibility: JPEG, JPG for high - quality photo viewing.
Other Features
Operating Range: 0 - 50°C, suitable for diverse environments.
Multilingual OSD: Catering to a global user base.
Certified Quality: 3C, FCC, CE, ROHS compliant.
Package Contents
Power Adapter: 12V/3A for stable power.
User Manual: For easy setup and operation.
The 18.5" Android Touch Screen Monitor KR3566 is your go - to choice for a high - performance, versatile display solution.
| Display | Panel | 18.5" high-definition full view screen | ||||||||||||
| Resolution | 1920x1080 | |||||||||||||
| Viewing angle | IPS Screen 85/85/85/85(L/R/U/D) | |||||||||||||
| Brightness | 300 cd/m2 | |||||||||||||
| Contrast | 1000:1 | |||||||||||||
| Screen scale/Display area | 16:9/ Display area : 409×229mm | |||||||||||||
| System | CPU | Rockchip RK3566 Quad Core 64 bit Cortex-A55 | ||||||||||||
| RAM | 2GB (4GB optional) | |||||||||||||
| Internal memory | 16GB (32GB optional) | |||||||||||||
| Operation system | Android 11/13 OS | |||||||||||||
| Touch screen | No 10-Point capacitive touch | |||||||||||||
| Network | WIFI | 802.11b/g/n | ||||||||||||
| Ethernet | 100M ethernet (1000M optional) | |||||||||||||
| Bluetooth | BT 5.2 | |||||||||||||
| 4G/5G Cellular network | Optional | |||||||||||||
| Interface | TF | TF card slots | ||||||||||||
| USB 2.0 | 1×USB 2.0 interface (support U disk, mouse, keyboard, printer etc) | |||||||||||||
| USB 3.0 | 1×USB 3.0 interface (support U disk, mouse, keyboard, printer etc) | |||||||||||||
| RJ45 | Ethernet interface (POE function Optional) | |||||||||||||
| Earphone | 1×3.5mm headphone Interface | |||||||||||||
| HDMI out | 1xHDMI out | |||||||||||||
| Power | DC power input (5.5x2.1) | |||||||||||||
| Multi-Media | Video | Support MPEG-1, MPEG-2, MPEG-4, H.263, H.264, RV, etc. (max support 1080P) | ||||||||||||
| Audio | Support MP3, WMA, AAC and so on | |||||||||||||
| Picture | JPEG,JPG | |||||||||||||
| Other parameters | Microphone | No | ||||||||||||
| Speaker | 2×3W speakers | |||||||||||||
| Camera | No | |||||||||||||
| Working temp | 0-50degree | |||||||||||||
| OSD language | Multi-language | |||||||||||||
| Certificates | 3C,FCC,CE,ROHS etc. | |||||||||||||
| Attachment | Adapter | yes, specifications: 12V/3A | ||||||||||||
| User's Manual | yes | |||||||||||||
| Desktop Bracket | No | |||||||||||||
| Body Size | Color Box | 5pcs/Carton | ||||||
| Length | Width | Thickness | Length | Width | Height | Length | Width | Height |
| 447 | 267 | 41 | 502 | 429 | 87 | 515 | 450 | 445 |
| N.W | 2.76KG | N.W | 3.46KG | N.W | 17.3KG | |||
| G.W | 18.3KG | |||||||
