18.5 Inch Wall Mounted Android AIO Tablet PC KR3288 IPS Display POE RJ45 Port No Camera

18.5 Inch Wall Mounted Android AIO Tablet PC KR3288 IPS Display POE RJ45 Port No Camera
18.5 Inch Wall Mounted Android AIO Tablet PC KR3288 IPS Display POE RJ45 Port No Camera 18.5 Inch Wall Mounted Android AIO Tablet PC KR3288 IPS Display POE RJ45 Port No Camera 18.5 Inch Wall Mounted Android AIO Tablet PC KR3288 IPS Display POE RJ45 Port No Camera 18.5 Inch Wall Mounted Android AIO Tablet PC KR3288 IPS Display POE RJ45 Port No Camera 18.5 Inch Wall Mounted Android AIO Tablet PC KR3288 IPS Display POE RJ45 Port No Camera 18.5 Inch Wall Mounted Android AIO Tablet PC KR3288 IPS Display POE RJ45 Port No Camera

Large Image :  18.5 Inch Wall Mounted Android AIO Tablet PC KR3288 IPS Display POE RJ45 Port No Camera

Product Details:
Place of Origin: China
Brand Name: OEM
Certification: 3C,FCC,CE,ROHS etc.
Model Number: N185N-3288
Payment & Shipping Terms:
Minimum Order Quantity: 2
Price: Negotiable based on order quantity
Packaging Details: 5pcs per carton, securely packaged.
Delivery Time: 1-5 weeks
Payment Terms: L/C, T/T, Western Union, Paypal
Supply Ability: 10k pcs per months

18.5 Inch Wall Mounted Android AIO Tablet PC KR3288 IPS Display POE RJ45 Port No Camera

Description
Panel: 18.5" High-definition Full View Screen Resolution: 1366×768 (1920x1080 Optional)
Viewing Angle: 85/85/85/85(L/R/U/D) Brightness: 300 Cd/m2
Screen Scale/Display Area: 16:9/ Display Area : 409×229mm CPU: Rockchip RK3288 Quad Core Cortex-A17, With Up To 1.8GHz Main Frequency
RAM: 2GB (4GB Optional) Internal Memory: 16GB (32GB Optional)
Operation System: Android 5.1/6.0/7.1/8.1/9.0/10 OS Touch Screen: 10-Point Capacitive Touch (optional)
Network: WIFI,Ethernet,Bluetooth,4G/5G Cellular Network Interface: TF, USB 2.0,USB 3.0,RJ45,Earphone,HDMI Out,Power
Camera: Non Speaker: 2×3W Speakers
Adapter: 12V/3A Desktop Bracket: Non (Optional)
Microphone: Non (Optional)
Highlight:

RJ45 Port Android AIO Tablet PC

,

18.5 Inch Android AIO Tablet PC

,

POE Android AIO Tablet PC

18.5 Inch Wall Mounted Android AIO Tablet PC KR3288 IPS Display POE RJ45 Port No Camera product Introduction



The 18.5 - Inch Wall - Mounted Android AIO Tablet PC KR3288 is a versatile and high - performance device designed to meet various needs.

Display
Featuring an IPS display, it offers a wide viewing angle of 178°, ensuring clear visibility from almost any position. The screen provides a sharp resolution, presenting vivid and detailed images. Whether for business presentations or digital signage use, the display quality is top - notch.

Hardware Configuration
Powered by a reliable Android system, it comes with a capable processor, ensuring smooth operation. It has sufficient RAM and internal storage to handle multitasking and store important data. With support for a POE RJ45 port, it simplifies the power and network connection, making installation and use more convenient.

Functionality
This tablet PC is wall - mountable, making it an ideal choice for public areas, offices, or industrial settings. It can be used for digital signage, showing announcements, promotions, or information. In an office environment, it can serve as a smart meeting device, facilitating communication and collaboration.

No - Camera Design
Lacking a camera, this model is optimized for applications where privacy or specific functionality requirements don't demand visual input. It focuses on other key features like display and connectivity.

Applications
It is suitable for a wide range of applications, such as industrial control panels, where stable performance and network connectivity are crucial. In retail stores, it can be used for advertising and product information display. Additionally, in educational institutions, it can be used for presenting educational materials in classrooms or common areas.

Overall, the 18.5 - Inch Wall - Mounted Android AIO Tablet PC KR3288, with its unique features and capabilities, is a reliable option for those seeking a high - quality, functional display device.
Product Information

Display Panel 18.5" high-definition full view screen
Resolution 1920x1080
Viewing angle IPS Screen 85/85/85/85(L/R/U/D)
Brightness 300 cd/m2
Contrast 1000:1
Screen scale/Display area 16:9/ Display area : 409×229mm
System CPU Rockchip RK3288 Quad Core Cortex-A17, with up to 1.8GHz main frequency
RAM 2GB (4GB optional)
Internal memory 16GB (32GB optional)
Operation system Android 5.1/6.0/7.1/8.1/9.0/10 OS
Touch screen No 10-Point capacitive touch
Network WIFI 802.11b/g/n
Ethernet 100M ethernet (1000M optional)
Bluetooth BT 5.2
4G/5G Cellular network Optional
Interface TF TF card slots
USB 2.0 1×USB 2.0 interface (support U disk, mouse, keyboard, printer etc)
USB 3.0 1×USB 3.0 interface (support U disk, mouse, keyboard, printer etc)
RJ45 Ethernet interface (POE function Optional)
Earphone 1×3.5mm headphone Interface
HDMI out 1xHDMI out
Power DC power input (5.5x2.1)
Multi-Media Video Support MPEG-1, MPEG-2, MPEG-4, H.263, H.264, RV, etc. (max support 1080P)
Audio Support MP3, WMA, AAC and so on
Picture JPEG,JPG
Other parameters Microphone No
Speaker 2×3W speakers
Camera No
Working temp 0-50degree
OSD language Multi-language
Certificates 3C,FCC,CE,ROHS etc.
Attachment Adapter yes, specifications: 12V/3A
User's Manual yes
Desktop Bracket No


Product Size

Body Size Color Box 5pcs/Carton
Length Width Thickness Length Width Height Length Width Height
447 267 41 502 429 87 515 450 445
N.W 2.76KG N.W 3.46KG N.W 17.3KG
            G.W 18.3KG
Unit: mm
