L-shaped 14 Inch Android Touchscreen Monitor Built-in 2GB+16GB Memory With RJ45 POE HDMI

L-shaped 14 Inch Android Touchscreen Monitor Built-in 2GB+16GB Memory With RJ45 POE HDMI
L-shaped 14 Inch Android Touchscreen Monitor Built-in 2GB+16GB Memory With RJ45 POE HDMI
L-shaped 14 Inch Android Touchscreen Monitor Built-in 2GB+16GB Memory With RJ45 POE HDMI L-shaped 14 Inch Android Touchscreen Monitor Built-in 2GB+16GB Memory With RJ45 POE HDMI L-shaped 14 Inch Android Touchscreen Monitor Built-in 2GB+16GB Memory With RJ45 POE HDMI L-shaped 14 Inch Android Touchscreen Monitor Built-in 2GB+16GB Memory With RJ45 POE HDMI L-shaped 14 Inch Android Touchscreen Monitor Built-in 2GB+16GB Memory With RJ45 POE HDMI

Large Image :  L-shaped 14 Inch Android Touchscreen Monitor Built-in 2GB+16GB Memory With RJ45 POE HDMI

Product Details:
Place of Origin: ShenZhen / China
Brand Name: SAEF
Certification: ISO9001 / ISO14000
Model Number: LS140T-3568
Payment & Shipping Terms:
Minimum Order Quantity: 2 pcs
Price: Negotiable based on order quantity
Packaging Details: Standard Exportation Package
Delivery Time: 1-5 weeks
Payment Terms: L/C, T/T, Western Union, Paypal
Supply Ability: 3000K pcs per month
Contact Now

L-shaped 14 Inch Android Touchscreen Monitor Built-in 2GB+16GB Memory With RJ45 POE HDMI

Description
Product: 14" Android Display Touch Screen Resolution: 1080*1920 Dots
Brightness: 300 Cdm2 Display Area: 175.8×311.6mm (16:9)
CPU: RK3568 RAM: 2GB
ROM: 16GB System: Android 11/13 OS
WIFI: 802.11b/g/n Multi-Media: Video/Audio/Picture
Speaker: 2×2W Speakers Camera: Standard 200W Pixel Camera
Adapter: One, 12V/2A POE: Optional
Highlight:

14 inch Android Touchscreen Monitor

,

RJ45 Android Touchscreen Monitor

,

L-shaped Android Touchscreen Monitor

About this item LS140T-3568 L-Shaped 14-Inch Portrait Android Touch Display



L-shaped 14 inch Android touchscreen display, with built-in 2GB+16GB memory and Android 11 operating system, equipped with RJ45, POE, HDMI interfaces, is a multifunctional commercial and industrial grade display device. The following is a detailed introduction of the product:

  1. Display Features: The 14 inch display provides a spacious visual experience, suitable for various commercial and industrial applications. Touchscreen technology allows users to operate directly on the screen, providing an intuitive way of interaction.

  2. Memory and Storage:Built in 2GB RAM and 16GB storage space, capable of meeting basic application running and data storage needs.

  3. Operating System:Equipped with the Android 11 operating system, it provides a rich application ecosystem and stable operating experience.

  4. Network Connection: The RJ45 interface supports wired network connections to ensure stable network performance. The POE (Power over Ethernet) function allows power to be supplied through Ethernet cables, simplifying wiring and reducing installation costs.

  5. Video interface:The HDMI interface supports high-definition video signal input, making it easy to connect to external video sources.

  6. Application Scenarios: Suitable for various occasions such as retail, catering, hotels, medical, industrial control, etc., used as information display, advertising playback or control panel.

  7. Installation method: L-shaped design, supporting wall mounted installation, saving space while maintaining a clean environment.

  8.

    Durability:The design meets industrial standards and can operate stably in harsh environments, such as wide temperature operation, dust and water resistance, etc.
  9. Scalability: In addition to basic network and video interfaces, other interfaces such as USB may also be provided to facilitate the connection of external devices.
  10. Technical Support: Provide detailed technical support and customized services to meet specific customer needs.

This L-shaped 14 inch Android touchscreen display, with its powerful features and flexible installation options, has become an ideal display and interactive device in commercial and industrial environments.





Features



Display Screen 14 inch IPS screen
Resolution 1080x1920
Brightness 300 cdm2
Contrast 1000:1
Screen scale/Display area 16:9/ Display area : 175.8×311.6mm
Configuration CPU Rockchip RK3568 quad core A55 processor, clocked 2.0GHz
RAM 2/4GB
ROM 16/32GB
System Android 11/13 system
Network WIFI 802.11b/g/n
Ethernet Supports connection to the RJ45 network interface
Bluetooth BT 4.2
3G/4G Support external 3G/4G USB dongle
Jack TF 1×TF card slots (max support 32GB)
USB 2.0 2×USB 2.0 interface (support U disk, mouse, keyboard, printer etc)
RJ45 1×RJ45 network interface
Earphone 1×3.5mm headphone jack
HDMI out 1xHDMI out
Power 1×5.5x2.1mm power DC jack
Multi-Media Video Support MPEG-1, MPEG-2, MPEG-4, H.263, H.264, RV, etc. (max support 1080P)
Audio Support MP3, WMA, AAC and so on
Picture JPEG,JPG
Other parameters Wireless mouse keyboard Support
Speaker 2×2W speakers
Camera Standard 2.0MP pixel camera (5.0MP pixel camera optional)
OSD language Chinese, English, German, Korean, Russian, French, Spanish, Arabia etc OSD operations
Software support Free installation applications (maps, games, e-mail, self developing apps, etc.)
Attachment Adapter One, specifications: 12V/2A
User's Manual One





Package



Body Size Color Box 6pcs/Carton
Length Width Thickness Length Width Height Length Width Height
345 205 116 395 170 255 780 405 275
N.W 1.18KG N.W 1.73KG N.W 10.4KG



Unit: mm





Mechanical Outline Drawing



L-shaped 14 Inch Android Touchscreen Monitor Built-in 2GB+16GB Memory With RJ45 POE HDMI 0

Product Details



L-shaped 14 Inch Android Touchscreen Monitor Built-in 2GB+16GB Memory With RJ45 POE HDMI 1L-shaped 14 Inch Android Touchscreen Monitor Built-in 2GB+16GB Memory With RJ45 POE HDMI 2

L-shaped 14 Inch Android Touchscreen Monitor Built-in 2GB+16GB Memory With RJ45 POE HDMI 3L-shaped 14 Inch Android Touchscreen Monitor Built-in 2GB+16GB Memory With RJ45 POE HDMI 4
