15.6-Inch Android 9.0 Touch Screen Display 1920x1080 Vesa Wall Wounted With POE Rj45 Port

15.6-Inch Android 9.0 Touch Screen Display 1920x1080 Vesa Wall Wounted With POE Rj45 Port
15.6-Inch Android 9.0 Touch Screen Display 1920x1080 Vesa Wall Wounted With POE Rj45 Port 15.6-Inch Android 9.0 Touch Screen Display 1920x1080 Vesa Wall Wounted With POE Rj45 Port 15.6-Inch Android 9.0 Touch Screen Display 1920x1080 Vesa Wall Wounted With POE Rj45 Port 15.6-Inch Android 9.0 Touch Screen Display 1920x1080 Vesa Wall Wounted With POE Rj45 Port 15.6-Inch Android 9.0 Touch Screen Display 1920x1080 Vesa Wall Wounted With POE Rj45 Port

Large Image :  15.6-Inch Android 9.0 Touch Screen Display 1920x1080 Vesa Wall Wounted With POE Rj45 Port

Product Details:
Place of Origin: ShenZhen / China
Brand Name: SAEF
Certification: ISO9001 / ISO14000
Model Number: XN156T-3288
Payment & Shipping Terms:
Minimum Order Quantity: 2 pcs
Price: Negotiable based on order quantity
Packaging Details: Standard Exportation Package
Delivery Time: 1-5 weeks
Payment Terms: L/C, T/T, Western Union, Paypal
Supply Ability: 3000K pcs per month

15.6-Inch Android 9.0 Touch Screen Display 1920x1080 Vesa Wall Wounted With POE Rj45 Port

Description
Product: 15.6 Inch Android Touch Screen Display Resolution: 1920×1080
Brightness: 350 Cdm2 Display Area: 16:9, 344.16×193.6mm
CPU: Rockchip RK3288 RAM: 2GB
ROM: 16GB System: Android 6.0/7.1/8.1/9.0/10
WIFI: 802.11b/g/n Network: WIFI/Ethernet/Bluetooth/3G/4G/microphone
Interface: TF/USB/RJ45/Earphone/Power/HD Out Multi-Media: Video/Audio/Picture
Speaker: 2×2W Speakers Camera: Standard 200W Pixel Camera
Software: Free Installation Applications Adapter: DC-In 12V/2A
User's Manual: One POE: Optional
Highlight:

Android 9.0 Touch Screen Display

,

15.6 Inch Android Touch Screen Display

,

Rj45 Port Android Touch Screen Display



15.6-inch KR3288 Android Touch screen Display Product Introduction



XN156T-3288 is an astonishing 15.6-inch android touch screen display.
It is equipped with a powerful RK3288 motherboard and can run Android 6.0/7.1/8.1/9.0/10 system, bringing an unparalleled intelligent experience. With a high-definition resolution of 1920x1080, the picture is delicate and vivid, and every detail is presented splendidly, bringing a shocking visual feast. The memory configurations are diverse. Whether it's 2G + 16G or 4G + 32G, you can choose according to your different needs and easily handle multitasking and massive storage.
The advantages of this product are extremely prominent. The interfaces are rich and diverse. The TF card slot is convenient for expanding storage; the USB2.0 and USB3.0 interfaces enable high-speed data transmission with extraordinary efficiency; the RJ45 network interface ensures a stable network connection, allowing you to be online at any time and enjoy the Internet world; the 3.5mm headphone jack creates a private music space; the HDMI output interface connects to a large screen and doubles the excitement. At the same time, the 5.5x2.1mm power DC jack provides stable power supply without worry.
Moreover, it also supports Vesa wall mounting, which is flexible and convenient for installation and can adapt to various space requirements. POE is optional, providing more convenience for use. It comes with a camera and microphone, which can easily handle video calls or online meetings. The touch screen design brings a new interactive experience with smooth operation. The Bluetooth function makes the connection more convenient and can be quickly paired with various devices. And it supports APP download. The rich application resources meet all your needs.
Whether it's for improving efficiency at work, enjoying excitement in entertainment, or acquiring knowledge in learning, XN156T-3288 is your ideal choice. With its excellent performance, rich functions, and outstanding design, it takes you to experience the charm of technology and start a new journey of wonderful life.

Product Information

Display Screen 15.6 inch FULL HD IPS screen
Resolution 1920×1080
Brightness 350 cdm2
Contrast 1000:1
Screen scale/Display area 16:9/ Display area :344×194mm
Configuration CPU Rockchip RK3568 quad core A55 processor, clocked 2.0GHz
RAM 2GB
ROM 16GB
System Android 6.0/7.1/8.1/9.0/10 system
Network WIFI 802.11b/g/n/ac
Ethernet Supports connection to the RJ45 network interface
Bluetooth Bluetooth 4.0
3G/4G Support external 3G/4G USB dongle
Built-in POE Optional
Built-in battery Optional
Jack TF 1×TF card slots (max support 32GB)
USB 2.0 1×USB 2.0 interface (support U disk, mouse, keyboard, printer etc)
USB 3.0 1×USB 3.0 interface
RJ45 1xRJ45
Earphone 1×3.5mm headphone jack
HDMI out 1xHDMI out
Power 1×5.5x2.1mm power DC jack
Multi-Media Video Support MPEG-1, MPEG-2, MPEG-4, H.263, H.264, RV, etc. (max support 1080P)
Audio Support MP3, WMA, AAC and so on
Picture JPEG,JPG
Other parameters Wireless mouse keyboard Support
Speaker 2×2W speakers
Camera Standard 200W pixel camera (500W pixel camera optional)
OSD language Chinese, English, German, Korean, Russian, French, Spanish, Arabia etc OSD operations
Software support Free installation applications (maps, games, e-mail, self developing apps, etc.)
Attachment Adapter One, specifications: 12V/2A
Desktop Bracket One
Remote control Optional
User's Manual One
Theftproof cover plate One, (can cover insert devices, such as U disk or SD card, to prevent theft)


Product Size

Body Size Color Box 10pcs/Carton
Length Width Thickness Length Width Height Length Width Height
391 240 30 440 350 76 445 400 730
N.W: 1.5KG N.W: 2.18KG G.W:22.8KG
Unit: mm
