21.5 Inch Wall Mounted Touch Screen Monitor RK3399 Powered Android 11 Tablet PC With RJ45 Poe Power RFID And NFC Capabilities

21.5 Inch Wall Mounted Touch Screen Monitor RK3399 Powered Android 11 Tablet PC With RJ45 Poe Power RFID And NFC Capabilities
21.5 Inch Wall Mounted Touch Screen Monitor RK3399 Powered Android 11 Tablet PC With RJ45 Poe Power RFID And NFC Capabilities 21.5 Inch Wall Mounted Touch Screen Monitor RK3399 Powered Android 11 Tablet PC With RJ45 Poe Power RFID And NFC Capabilities 21.5 Inch Wall Mounted Touch Screen Monitor RK3399 Powered Android 11 Tablet PC With RJ45 Poe Power RFID And NFC Capabilities 21.5 Inch Wall Mounted Touch Screen Monitor RK3399 Powered Android 11 Tablet PC With RJ45 Poe Power RFID And NFC Capabilities 21.5 Inch Wall Mounted Touch Screen Monitor RK3399 Powered Android 11 Tablet PC With RJ45 Poe Power RFID And NFC Capabilities 21.5 Inch Wall Mounted Touch Screen Monitor RK3399 Powered Android 11 Tablet PC With RJ45 Poe Power RFID And NFC Capabilities 21.5 Inch Wall Mounted Touch Screen Monitor RK3399 Powered Android 11 Tablet PC With RJ45 Poe Power RFID And NFC Capabilities 21.5 Inch Wall Mounted Touch Screen Monitor RK3399 Powered Android 11 Tablet PC With RJ45 Poe Power RFID And NFC Capabilities

Large Image :  21.5 Inch Wall Mounted Touch Screen Monitor RK3399 Powered Android 11 Tablet PC With RJ45 Poe Power RFID And NFC Capabilities

Product Details:
Place of Origin: ShenZhen / China
Brand Name: SAEF
Certification: ISO9001 / ISO14000
Model Number: SF-Y215T
Payment & Shipping Terms:
Minimum Order Quantity: 2 pcs
Price: Negotiable based on order lot quantity
Packaging Details: Standard Exportation Package
Delivery Time: 3-5 weeks
Payment Terms: L/C, T/T, Western Union, Paypal
Supply Ability: 3000K pcs per month

21.5 Inch Wall Mounted Touch Screen Monitor RK3399 Powered Android 11 Tablet PC With RJ45 Poe Power RFID And NFC Capabilities

Description
Product: 21.5" Inch Touch Screen Monitors Resolution: 1920×1080
Brightness: 350 Cdm2 Screen Scale/Display Area: 16:9/ Display Area :479×270.5mm
CPU: Rockchip RK3399 Dual Core Cortex-A72 Up To 1.8GHz+quad Core Cortex-A53 Up To 1.4GHz RAM: 4GB
ROM: 16GB System: Android 11 OS
WIFI: 802.11b/g/n/ac Network: WIFI/Ethernet/Bluetooth/3G/4G/microphone
Interface: 1×SD/1xType-c/2×USB 2.0/1×USB 3.0/1×RJ45/1×3.5mm Headphone Jack/1×4.0mm Power DC Jack Multi-Media: Video/Audio/Picture
Wireless Mouse Keyboard: Support Speaker: 2×3W Speakers
Camera: Standard 200W Pixel Camera OSD Language: Chinese, English, German, Korean, Russian, French, Spanish, Arabia Etc OSD Operations
Software Support: Free Installation Applications (maps, Games, E-mail, Self Developing Apps, Etc.) Adapter: One, Specifications: 12V/3A
User's Manual: One POE: Optional
Capacitive Touch Screen: Yes
Highlight:

Android 11 Tablet PC

21.5 - Inch Wall - Mounted Touch Screen Monitor: Unleashing Unmatched Performance and Versatility

Exceptional Performance with RK3399

Powered by the high - performance RK3399 processor, this 21.5 - inch wall - mounted touch screen monitor is a powerhouse. The RK3399 ensures smooth multitasking and fast - paced operation, whether you're running complex applications or handling multiple tasks simultaneously. It supports various Android operating systems, including 7.1, 8.1, 9.0, 10, and 11, giving you the flexibility to choose the version that best suits your needs.

Stunning Visuals

Featuring a 1920x1080 high - definition resolution, every image and video on this monitor comes to life with vibrant colors and sharp details. The large 21.5 - inch touch - screen display offers an immersive viewing experience, making it perfect for both personal and professional use.

Ample Storage and Memory

Equipped with 4GB of RAM and 32GB of internal storage, this tablet PC provides enough space to store your apps, files, and media. The 1×SD card slot allows for easy expansion of storage, ensuring you never run out of space.

Rich Connectivity Options

The device offers a comprehensive range of connectivity ports:
  • 1xType - c: For fast data transfer and charging.
  • 2×USB 2.0 and 1×USB 3.0: Ideal for connecting external devices such as keyboards, mice, and flash drives.
  • 1×RJ45: For stable Ethernet connection, especially useful for applications that require high - speed and reliable network access.
  • 1×3.5mm headphone jack: Enables you to enjoy audio privately.
  • 1×4.0mm power DC jack: Ensures a stable power supply.

Special Features: RFID and NFC Capabilities

With built - in RFID and NFC capabilities, this monitor is well - suited for applications that require secure identification and contactless communication. It can be used in access control systems, payment terminals, and more.

Wide - range Applications

  • Retail and Hospitality: Use it as a point - of - sale (POS) system, digital menu board, or customer information kiosk.
  • Education: Ideal for interactive classrooms, allowing teachers and students to engage in hands - on learning experiences.
  • Industrial and Manufacturing: Serve as a control panel for monitoring and managing industrial processes.
  • Healthcare: Assist in patient registration, medical record access, and telemedicine applications.
In summary, the Y215T - 3399 is not just a monitor; it's a versatile solution that combines powerful performance, rich features, and wide - range applications to meet the diverse needs of modern users.


Product Specification Reference
Display Screen 21.5 inch FULL HD IPS screen
Resolution 1920*1080
Brightness 350 cdm2
Contrast 1000:1
Screen scale/Display area 16:9/ Display area : 479×270 mm
Configuration CPU Rockchip RK3399 Dual core Cortex-A72 + Quad core Cortex-A53 CPU
GPU ARM Mali-T860MP4 GPU
RAM 4G
ROM 16G (Standard 32GB)
System Android 11 OS
Network WIFI 802.11b/g/n
Ethernet Supports connection to the RJ45 network interface
Bluetooth Bluetooth 4.0
3G/4G Support external 3G/4G USB dongle
Jack SD 1×SD card slots (max support 32GB)
Mini USB 1×USB OTG (through it to debug the machine, brush the system program)
USB 2.0 3×USB 2.0 interface (support U disk, mouse, keyboard, printer etc)
RJ45 1×RJ45 network interface
Earphone 1×3.5mm headphone jack
Power 1×4.0mm power DC jack
Multi-Media Video Support MPEG-1, MPEG-2, MPEG-4, H.263, H.264, RV, etc. (max support 1080P)
Audio Support MP3, WMA, AAC and so on
Picture JPEG,JPG
Other parameters Wireless mouse keyboard Support
Speaker 2×3W speakers
Camera Standard 200W pixel camera (500W pixel camera optional)
OSD language Chinese, English, German, Korean, Russian, French, Spanish, Arabia etc OSD operations
Software support Free installation applications (maps, games, e-mail, self developing apps, etc.)
Attachment Adapter One, specifications: 12V/3A
Desktop Bracket One
Remote control Optional
User's Manual One
Theftproof cover plate One, (can cover insert devices, such as U disk or SD card, to prevent theft)



Body Size Color Box 4pcs/Carton
Length Width Thickness Length Width Height Length Width Height
530 322 36 590 100 415 620 440 460
N.W 3.5KG N.W 4.3KG N.W 17.2KG
            G.W 18.8KG

Product size, Unit: mm







21.5 Inch Wall Mounted Touch Screen Monitor RK3399 Powered Android 11 Tablet PC With RJ45 Poe Power RFID And NFC Capabilities Product Image
21.5 Inch Wall Mounted Touch Screen Monitor RK3399 Powered Android 11 Tablet PC With RJ45 Poe Power RFID And NFC Capabilities 021.5 Inch Wall Mounted Touch Screen Monitor RK3399 Powered Android 11 Tablet PC With RJ45 Poe Power RFID And NFC Capabilities 121.5 Inch Wall Mounted Touch Screen Monitor RK3399 Powered Android 11 Tablet PC With RJ45 Poe Power RFID And NFC Capabilities 221.5 Inch Wall Mounted Touch Screen Monitor RK3399 Powered Android 11 Tablet PC With RJ45 Poe Power RFID And NFC Capabilities 321.5 Inch Wall Mounted Touch Screen Monitor RK3399 Powered Android 11 Tablet PC With RJ45 Poe Power RFID And NFC Capabilities 4

Product Packaging

21.5 Inch Wall Mounted Touch Screen Monitor RK3399 Powered Android 11 Tablet PC With RJ45 Poe Power RFID And NFC Capabilities 5

Product Application Scenarios

21.5 Inch Wall Mounted Touch Screen Monitor RK3399 Powered Android 11 Tablet PC With RJ45 Poe Power RFID And NFC Capabilities 6



Quality Management
1. Quality policy
Provide sound quality and deliver goods on time;
To satisfy requirements of customers with continuous improvement
2. EHS policy
To observe laws and regulations and to prevent and control pollution;
To try to reduce emission and conserve and make full use of resources;
To improve environmental protection awareness and continuously improve the environment;
3. Measures adopted
It will make transparent its quality policy and improve employees’ awareness on quality via training and education;
By implementing ‘5S’ management, it will make office and production spot tidy and orderly and employees well-trained;
It will make sure that the ISO9001 quality guarantee system cover all rounds affecting qualities of products and services before incorporating them to regulated and procedural management and control;
Under the premise that quality is guaranteed, it will reduce production costs including reduction of costs of raw materials and improvement of production and managerial efficiency.



Factory Facilities and Certificates

21.5 Inch Wall Mounted Touch Screen Monitor RK3399 Powered Android 11 Tablet PC With RJ45 Poe Power RFID And NFC Capabilities 721.5 Inch Wall Mounted Touch Screen Monitor RK3399 Powered Android 11 Tablet PC With RJ45 Poe Power RFID And NFC Capabilities 8




FAQ:
1. Q: Are you a factory?
A: Yes, we are factory.we produce tablet pc from 2007.
2. Q: How much extra cost for your OEM order?
A: No extra cost for our OEM service if order qty over 50pcs.
3. Q: How long is the leading time?
A: 3-7days for sample orders. 10-15days for mass production orders
4. Q: How will you ship the goods for me?
A: Ship by air by sea and express. We cooperate with international expresses such as DHL, UPS, FedEx,TNT to enable our customers get their goods rapidly.
