Product Details:
|
| Product: | 4 Digits 7 Segments LCD Display | Display Mode: | Positive Transflective/Reflective |
|---|---|---|---|
| Driving Condition: | Static | Operating Voltage: | 3.0 V |
| Optics: | All Viewing Angles | Display Type: | LCD |
| Size: | 2.4 Inch | Backlight: | White / Amber / Blue / Yellow |
| Operating Temp: | -30°C To +80°C | Storage Temp.: | -35°C To +85°C |
| Connection: | Metal Pin Connection | Compliance: | REACH & RoHS Compliant |
| Dot Space: | 0.1 Mm | Response Time: | 0.1 Ms |
| Highlight: | Monochrome 7 Segment LCD Display,4 Digit 7 Segment LCD Display,8 Digits 7 Segment LCD Display |
||
7 Segment LCD Display, 4 Digit 8 Digits 7 segments LCD, Monochrome Lcd Display, Lcd Numeric Display
SAEF Technology is specializing in the production of customized 7-segment LCD displays. As a leading LCD manufacturer in China, we believe and continue to conduct in-depth research and development, which has led to breakthrough developments in the field of liquid crystal displays. Our high-end displays are used in a wide range of applications in industrial, residential, automotive, medical, and consumer products.
| Product: | 4 digits 7-Segment LCD Display | Display Mode: | Positive Transflective/reflective |
|---|---|---|---|
| Driving Condition: | Static | Operating Voltage: | 3.0 V |
| Optics: | All Viewing Angles | Display Type: | LCD |
| Size: | 2.4 Inch | Backlight: | White / Amber / Blue / Yellow |
| Operating Temp: | -30°C To +80°C | Storage Temp.: | -35°C To +85°C |
| Connection: | Metal Pin Connection | Compliance: | REACH & RoHS Compliant |
| Dot Space: | 0.1 Mm | Response Time: | 0.1 Ms |
7 Segment LCD Display, 4 Digit 8 Digits 7 segments LCD, Monochrome Lcd Display, Lcd Numeric Display
Segment LCD screen, refers to a fixed LCD screen that is displayed or not displayed in a specified position, which can only be used for simple display of numbers and characters, mainly to replace the LED digital tube (composed of 7 pen segments, used to display the number 0~9). Widely used in: automotive instruments, beauty instruments, small household appliances, watches, electronic scales, clocks, landlines, calculators and other products, the content displayed is digital and relatively simple. (as shown below)
The main difference between the dot matrix screen and the segment screen is: the segment LCD screen can only display characters and numbers, while the dot matrix LCD screen can not only display numbers but also display graphy and images, and the segment LCD screen is much cheaper in price.
